HEICO-LOCK®
HLK-WASHERS FOR STEEL CONSTRUCTION

  • Designed to secure HV sets according to DIN EN 14399-4 and DIN EN 14399-8

  • Replacing washers according to DIN EN 14399-6

  • Can be used for bolted connections of cat. A to E according to DIN EN 1993-1-8, a. o. suitable for slip-resistant connections

  • Certified construction product (certificate of conformity)

  • Approved for use by General Building Supervisory Authority (DIBt) Approval No Z-14.4-702

  • Approved for railway-specific applications (EBA approval)

  • Very easy to install and remove (HLK-washers are supplied as a pre-assembled pair)

  • The double chamfer also ensures that the HEICO-LOCK® HLK-Washers cannot be applied incorrectly, so avoiding operator error

  • High corrosion resistance provided by use of a zinc-flake coating

  • Available for HV sets from M12 up to M36

The HEICO-LOCK® HLK-Washers offer high quality anti-vibration security for HV sets according to DIN EN 14399-4 and DIN EN 14399-8.

Even under extremes of vibration or severe dynamic loads in steel construction the HEICO-LOCK® HLK-Washers, which are approved by the German Institute for Structural Engineering (DIBt), provide maximum reliability. Due to the increased under head radius of HV bolts, the HEICO-LOCK® HLK-Washers are chamfered on the internal diameter to ensure optimal surface contact while tightening.
